ATTEN ST-8800D Hot Air Station

ATTEN ST-8800D is an intelligent 800W Hot Air Rework Station designed for SMD component removal, PCB/PCBA repair, electronics maintenance and professional rework applications.

It provides an adjustable 100°C to 500°C temperature range and 30–120 L/min airflow. The airflow can be adjusted from 10% to 100%, allowing the operator to select suitable heat and airflow settings for different components and rework processes.

The ST-8800D features an LCD display and three programmable shortcut settings for storing frequently used temperature and airflow combinations. It also supports temperature lock, temperature calibration, automatic standby/sleep and password protection.

The hot-air system uses the AP-800B handle and includes automatic cooling to help protect the heating element and handle after use. ATTEN also provides a dedicated cold-air function for applications where heating is not required.

Technical Specifications

Parameter	Specification
Brand	ATTEN
Model	ST-8800D
Product Type	Intelligent Hot Air Rework Station
Input Voltage	AC 230V ±10%, 50Hz / AC 110V ±10%, 60Hz
Power	800W
Temperature Range	100°C – 500°C
Air Flow	30 – 120 L/min
Air Volume Setting	10% – 100%
Temperature Compensation	±50°C
Temperature Unit	°C / °F
Display	LCD
Hot Air Handle	AP-800B
Heating Element	HR-2700A
Quick Settings	3 Sets
Temperature Lock	Supported
Temperature Calibration	Supported
Automatic Standby / Sleep	Supported
Cold Air Function	Supported
Automatic Cooling	Supported
Timing Function	10 – 900 Seconds
Password Protection	Supported
Beep Alarm	Supported
Working Conditions	0°C – 40°C, <80% RH
Storage Conditions	-20°C – 80°C, <80% RH
Main Unit Dimensions	167(L) × 142(W) × 148(H) mm
Primary Application	SMD Rework, PCB / PCBA Repair, Component Desoldering & Electronics Maintenance

Key Features

800W hot-air rework station
100°C–500°C temperature range
30–120 L/min adjustable airflow
10%–100% airflow setting
AP-800B hot-air handle
LCD operating display
3 programmable temperature/airflow presets
Temperature lock function
Temperature calibration
°C / °F selection
Automatic standby and sleep
Automatic heater cooling
Independent cold-air function
10–900 second timer
Password-protected settings
Brushless fan system
Four standard nozzles

Applications

SMD Rework – Controlled heating for removal and installation of compatible SMD components.
PCB / PCBA Repair – Hot-air processing during board-level repair and rework.
Component Desoldering – Removal of compatible components using controlled hot air.
IC Rework – Suitable for compatible surface-mount IC packages.
Electronics Manufacturing – Suitable for production-line rework operations.
Repair & Maintenance – For electronics service and maintenance workstations.
R&D / Prototyping – Useful for PCB modification and prototype rework.
Education & Training – ATTEN lists education and practice among its applications.
